- Category:
- LED TAPE
- NEW PRODUCTS
- Series:
- BL Flexform
- LED TAPE
BL Flexform is a high-performance, specification-grade LED tape crafted for limitless architectural lighting possibilities.
Delivering up to 183 lm/FT of dot free illumination, our flexible, dimmable, DFS2 LED strip features side-emitting diodes that disperse light from the edge, for easy integration into complex shapes, such as circular coves, contours and height restricted spaces. Add architectural accents to niches, coves, bar shelves and displays, in commercial, residential, and retail environments.
Newly adapted for flexible linear lighting, this unique technology bonds the LED chips directly on the flexible circuit board (COB). The tiny LEDs are tightly spaced, up to 146 chips per foot, and topped with a thin phosphor coating. This allows for uniform diffusion, at a lower profile, and at higher light levels than a comparable surface mount (SMD) LED can achieve. The result is a flexible, homogeneous, dot-free lighting optic, offering the freedom to realize the most sophisticated lighting designs.
-
Features & Benefits
Side-Emitting
CRI 90+
Up to 183 LM/FT
Dot-Free
24V, 3.05W/FT
50,000 Hours Average Lifespan
Class 2, cULus Listed Low-Voltage Lighting System -
Certifications
-
Colors
-
2700K
-
3000K
-
4000K
-
-
Controls
0-10V MLV ELV Phase Cut Triac
DMX
0-10V
DMX
BL SYSTEMBUILDER - LIGHTING, POWER & CONTROL CONFIGURATOR TOOL
Your Product Code
-
Product Code
-
Series
-
Color
-
Input Voltage
-
Ingress Protection
Select options from the menu to generate a BL Product Code and create your a custom Data Sheet.
Download this document to supplement your design, specification, or to initiate a Bill of Materials with a BL Lighting rep. These are useful details that help us define your project.
1 Layout, Quantity, and other project specific requirements are unknown.
2 Custom Data Sheet is for illustrative purposes and is not an official specification sheet.
Please consult BL Lighting for further details regarding the information and specifics provided in this document. A detailed description of custom system specification to follow official RFQ. Please provide this custom document to the BL Lighting Quotations Department or appointed representative when requesting a Bill of Materials.
