The BL Inground Grazer Series comprises LED luminaires specifically engineered for ground and wall-recessed installations, offering robust and decorative linear lighting solutions. LG4, a sleek, trimless-design lighting solution, integrates seamlessly into outdoor environments. Its durable aluminum housing supports static loads up to 330lb (150kg) and provides up to 3470 lumens per unit. Featuring multiple beam angles, an optional anti-glare lens, and IP67 / IK08 protection, it ensures reliable, glare-free illumination for both commercial and residential in-ground applications.
-
Features & Benefits
Walk-Over Load Rating
330lbs Weight Bearing
4 Beam Angle Options
Up to 3470lm/unit
Two Diffuse Options: Clear Lens and Anti-Glare Lens
Operating Temperature -4°F to 122°F (-20°-50°C)
IP67 Rated LED for Wet or Dry Locations
50,000 Hours Lifespan
Aluminum Housing
Suitable for In-Ground and In-Floor Installations -
Certifications
-
Color/CCT
-
2700K
-
3000K
-
3500K
-
4000K
-
5000K
-
6500K
-
-
Downloads
-
Controls
0-10V TRIAC ELV
0-10V  and provides up to 3470 lumens...){kind=link}
BL SYSTEMBUILDER - LIGHTING, POWER & CONTROL CONFIGURATOR TOOL
Your Product Code
 and provides up to 3470 lumens...https://bllighting.com/products/luminaires/lg4/#PRODUCT_CODE){kind=link}
-
Product Code
-
Series
-
Length
-
CCT
-
Beam Angle
-
Diffuse
-
Control
-
Finish
-
Input Voltage
-
Ingress Protection
Select options from the menu to generate a BL Product Code and create your a custom Data Sheet.
Download this document to supplement your design, specification, or to initiate a Bill of Materials with a BL Lighting rep. These are useful details that help us define your project.
1 Layout, Quantity, and other project specific requirements are unknown.
2 Custom Data Sheet is for illustrative purposes and is not an official specification sheet.
Please consult BL Lighting for further details regarding the information and specifics provided in this document. A detailed description of custom system specification to follow official RFQ. Please provide this custom document to the BL Lighting Quotations Department or appointed representative when requesting a Bill of Materials.
